PCB Fabrication Services
Custom PCB Fabrication Services and Manufacturing Capabilities
PCBELEC provides custom PCB fabrication services for prototype, low-volume, and production requirements. We support a wide range of PCB manufacturing options, including multilayer boards, HDI structures, rigid-flex constructions, heavy copper designs, controlled impedance requirements, and application-specific material and surface finish selections.
PCB Fabrication Capabilities at a Glance
PCBELEC supports custom PCB fabrication for rigid, flexible, rigid-flex, HDI, metal core, heavy copper, and controlled impedance PCB projects. Our manufacturing capabilities cover single-sided boards through complex multilayer constructions, with support for prototype builds, repeat production, material selection, surface finish options, and electrical testing requirements.
Buyers and engineers often review fabrication capability by layer count, board thickness, copper weight, via structure, surface finish, and testing options before requesting a quotation. This page is designed to help you review those core manufacturing details more efficiently.
Core PCB Manufacturing Capabilities
The following overview highlights the main PCB fabrication capabilities buyers and engineers usually review before requesting a quotation. If your project includes special materials, controlled impedance, heavy copper, advanced via structures, or application-specific requirements, our team can review them based on your fabrication data and end-use needs.
Swipe horizontally to view the full table.
| Capability Area | Details |
|---|---|
| Board Types | Rigid PCB, Flexible PCB, Rigid-Flex PCB, HDI PCB, Metal Core PCB, Heavy Copper PCB, Controlled Impedance PCB |
| Layer Count | Single-sided, Double-sided, Multilayer PCB up to 64 layers; HDI PCB up to 32 layers |
| Line Width / Space | Down to 3mil / 3mil |
| Board Thickness | 0.1mm to 8.0mm |
| Maximum Board Size | Up to 533.4 × 762 mm |
| Via Structures | Blind vias, buried vias, via-in-pad, filled vias, laser drilling for HDI structures |
| Special Options | Controlled impedance, heavy copper, lead-free PCB, RoHS compliant fabrication |
| Materials | FR4, High Tg FR4, Rogers, Polyimide, Aluminum, Nelco, Halogen-Free, Shengyi, Isola, Arlon, Dupont, Nanya |
| Surface Finishes | OSP, HASL, Lead-Free HASL, ENIG, Immersion Silver, Immersion Tin, EPIG, ENEPIG, Gold Flash |
| Testing | Netlist testing, continuity testing, flying probe testing, interconnect stress testing, X-ray inspection |
PCB Fabrication Options We Support
We support a wide range of PCB fabrication projects for different structural, thermal, electrical, and reliability requirements. Common manufacturing options include multilayer PCBs, HDI PCBs, rigid boards, flex and rigid-flex constructions, heavy copper designs, metal core PCBs, high-frequency boards, and impedance-controlled PCB fabrication.
Materials, Surface Finishes and Testing Options
Material selection, surface finish choice, and testing requirements all affect PCB reliability, manufacturability, lead time, and end-use performance. We support a broad range of standard and application-specific fabrication options for both prototype and production PCB requirements.
PCB Materials
Available material options include FR4, High Tg FR4, Rogers, Polyimide, Aluminum, Nelco, Halogen-Free materials, Shengyi, Isola, Arlon, Dupont, and Nanya, depending on the project structure and application requirements.
Surface Finishes
We support OSP, HASL, Lead-Free HASL, ENIG, Immersion Silver, Immersion Tin, EPIG, ENEPIG, and Gold Flash to match different solderability, reliability, and performance requirements.
Testing and Inspection
Available testing and inspection options include netlist testing, continuity testing, flying probe testing, interconnect stress testing, and X-ray inspection for applicable PCB fabrication projects.
What to Prepare Before Requesting a PCB Quote
To receive a faster and more accurate PCB fabrication quotation, please prepare your Gerber files or fabrication drawings together with the main manufacturing requirements. Clear project information helps our team review your PCB structure, material selection, surface finish, testing needs, and delivery expectations more efficiently.
Before submitting your inquiry, we recommend preparing the following details:
- Gerber files or fabrication drawings
- PCB type or application description
- Layer count
- Board dimensions and thickness
- Base material requirement
- Copper weight
- Surface finish requirement
- Quantity and target delivery schedule
If some details are still under review, you can still send the available files and project notes first, and our team can check the fabrication requirements based on the current data package.
PCB Fabrication FAQ
We support single-sided, double-sided, and multilayer PCB fabrication up to 64 layers. For advanced structures, HDI PCB fabrication is supported up to 32 layers depending on the project requirements.
Our listed manufacturing capability includes line width and spacing down to 3mil / 3mil for suitable PCB fabrication projects.
Our fabrication capability includes PCB thickness from 0.1 mm to 8.0 mm, depending on board structure, material system, and application requirements.
We support OSP, HASL, Lead-Free HASL, ENIG, Immersion Silver, Immersion Tin, EPIG, ENEPIG, and Gold Flash for different fabrication and application requirements.
Yes. We support controlled impedance PCB fabrication as well as HDI PCB structures with laser drilling, advanced via options, and project-based engineering review.
Available testing options include netlist testing, continuity testing, flying probe testing, interconnect stress testing, and X-ray inspection for applicable fabrication projects.
To prepare a quotation efficiently, we recommend sending Gerber files or fabrication drawings together with layer count, board dimensions, thickness, material requirements, copper weight, surface finish, quantity, and delivery targets.
Yes. PCBELEC supports prototype PCB fabrication as well as low-volume and production PCB manufacturing requirements across different board types and structures.
Ready to Request a PCB Fabrication Quote?
Send your Gerber files and fabrication requirements to receive a custom PCB quotation from our engineering and manufacturing team. We support prototype, low-volume, and production PCB manufacturing projects based on your technical specifications.
